Fifth Wheel
Ultraton Fifth Wheel Series is an important connection part working with Ultraton king pin with vertical load 20T and 28T.
- Overview
- Advantage
- Application
- Other notes
Overview of Fifth Wheel
Heavy duty and extra durability designed
Adopt one-piece design for stronger structure
Universal interchangeable wearable collar and locking assembly is available
Various oscillations available for different need
Advantage of Fifth Wheel
Mature technology and workmanship offers more stability, greater capacity and longer service life
Strictly selected material and parts protect high performance.
Complete quality control procedure can ensure good quality
Fast response and flexible service from our professional team
Distinct location to get full range support on delivery and manufacturing
Ultraton's long term tenet to be your reliable partner bringing you Greater value makes you worry free on after sales service
| Item | Mounting Height H (mm) | Vertical Load (kg) | D-Value (KN) | Oscillations (a) | Net Weight (kg) |
| U-FW90-160 | 160 | 28,000 | 190 | 8° | 167 |
| U-FW90-172 | 172 | 28,000 | 190 | 15° | 171 |
| U-FW90-182 | 182 | 28,000 | 190 | 17° | 172 |
| U-FW50-172 | 172 | 20,000 | 152 | 15° | 146 |
| U-FW90-150 | 150 | 20,000 | 152 | 13° | 145 |
| U-FW90-185 | 185 | 20,000 | 152 | 18° | 147 |
